Showing 1–24 of 35 results
-
-
-
Category Name, Electronics, Flight Controllers
DarwinFPV FPVCycle Whoop Stack Flight Controller 6S 45A ESC
Category Name, Electronics, Flight ControllersDarwinFPV FPVCycle Whoop Stack Flight Controller 6S 45A ESC
This is a unique stack for the demands of the industry today. It has a 25.5×25.5 M2 (Whoop) mount pattern because there are now many frames that are designed with that pattern. This stack can be used for everything from 3″ to 6″.
We split the ESC and FC but called for the ESC to have a nearly empty top side and the FC to have nearly all it’s components on the bottom and sit inside the footprint of the ESC solder pads. ALL of the FC’s solder pads are also on the TOP. When you assemble the stack inside your frame, you will be able to access and solder ALL pads on BOTH boards. Additionally, the FC has a black box chip which is rare on AIO boards.
SKU: DF.CYCLE.STACK.45A. -
Category Name, Electronics, Other Electronics
DarwinFPV Tiny Ape VTX 25/200/400/600 mW
DarwinFPV 600mW VTX is a light weight, small size, high quality 25-600mW VTX, it provides optional 25/200/400/600mW output power, integrated 4Pin socket, plug and play is very convenient. The VTX settings can be adjusted through the flight control, that is, the transmitted power, frequency band and channel.
Indicator Light Description:
Frequency and Power Control Method:
Adjust VTX frequency and power via Betaflight
①Connect the RX white line of VTX to the TX signal line or SOFTSERIAL1 signal line of the FC spare UART port;
②Select the port tab, enable the TBS (SmartAudio) function setting of the connected port and save it;(The above figure takes the TX signal line as an example; SOFTSERIAL1 is the same, just select the TBS (SmartAudio) function according to the corresponding port).
③ After entering the VTX parameter adjustment interface, select the desired frequency and power, and then “save” to save and exit.
SKU: DF.VTX.TINYAP. -
-
Analog, Category Name, Electronics, FPV Equipment, Other Electronics
Flywoo Finder Buzzer w/LED v1.0
The Finder is compatible with all BF and CF flight controls. Just connect to the buzzer interface of the flight controller and it will work. When the flight control wiring is correct, the multi-rotor aircraft is powered on, and the flight control power supply will be automatically charged for the Finder (the red LED will light to indicate charging is in progress, the red light is off to indicate charging saturation; the red light flashing indicates flight control) Electricity, enter 30 seconds waiting time).
The buzzer has two modes of operation
- It is compatible with the functions of the traditional active buzzer and synchronized with the flight control.
- When the flight control is normally connected, if the main battery in the flight is powered off, it can still automatically emit 100 dB of drip sound after 30 seconds of power failure, and the LED will emit white light.
To turn off the buzzer
Press and hold the release button for more than 2 seconds, the Finder V1.0 turns off the sound.
SKU: FW.FINDER.BUZZER. -
Category Name, Electronics, Other Electronics
Flywoo GOKU GM10 Mini V3 GPS
Flywoo’s GOKU GM10 V3 GPS series has arrived! Using the latest M10050 GNSS chip. Compared with the previous generation GM8 V2, the positioning is more accurate, and the speed of satellite search is faster.
Note: The chip of GOKU GM10 V3 GPS is M1005. Only BF4.3x version firmware can use Ublox protocol. BF4.2x and earlier firmware can only use NMEA protocol But there is no difference in performance between the two protocols
BETAFLIGHT:
Use firmware above 4.3.0
INAV:
Use the latest 6.0.0 configurator, the latest firmware above 5.0.0SKU: FW.10MV3.GPSM. -
Category Name, Electronics, Other Electronics
Flywoo GOKU GM10 Nano V3 GPS
The GOKU GM10 V3 GPS series has arrived! Using the M100500 GNSS chip. Compared with the previous generation GM8 V2, the positioning is more accurate, and the speed of satellite search is faster.
Note: The chip of GOKU GM10 V3 GPS is M1005. Only BF4.3x version firmware can use Ublox protocol. BF4.2x and earlier firmware can only use NMEA protocol But there is no difference in performance between the two protocols
BETAFLIGHT:
Use firmware above 4.3.0
INAV:
Use the latest 6.0.0 configurator, the latest firmware above 5.0.0SKU: FW.10NV3.GPSM. -
Category Name, Electronics, Flight Controllers
Flywoo GOKU GN 405S 40A AIO (MPU6000 ) 25.5 X 25.5
Flywoo’s new top GOKU series AIO are finally here! GOKU GN405 40A FC is an economical and durable all-in-one AIO , which can meet most your FPV needs.
Use powerful F405 chip , integrate 5V BEC, barometer, black box, WS2812LED, support 6 complete hardware serial ports, I2C and other functions are all open.SKU: FW.GOKU.405S.AIO. -
-
Category Name, Electronics, Flight Controllers
Happymodel CrossF4 F411 1-2S 5A AIO Whoop Flight Controller with UART ELRS v3.0 receiver – ELRS 2.4gHz
Category Name, Electronics, Flight ControllersHappymodel CrossF4 F411 1-2S 5A AIO Whoop Flight Controller with UART ELRS v3.0 receiver – ELRS 2.4gHz
HappyModel keeps them coming! Now with yet another fantastic whoop AIO. The HappyModel CrossF4 1-2S AIO Whoop Flight Controller (F4 FC / 5A 4in1 ESC) – Featuring F411 Flight Controller, with a built in serial UART ELRS for V3.0.
NOTE: Onboard blackbox enable method:
-Type the following command to CLI:
-set blackbox_device = SPIFLASH
-set flash_spi_bus = 2
-resource FLASH_CS 1 a14Pay attention: Bind procedure is the same like Happymodel EP1/EP2 receiver, as you need to upgrade your ExpressLRS TX module to V3.X version first.
Alternative-Binding-Method-for-UART-Based-ELRS-RX
Onboard blackbox enable method:
Type the following command to CLI:
set blackbox_device = SPIFLASH
set flash_spi_bus = 2
resource FLASH_CS 1 a14
saveSKU: HM.CROSSF.FC.ELRS -
Electronics, Flight Controllers
Happymodel DiamondF4 ELRS 5-in-1 AIO FC 2.4GHz
Happymodel’s AIO triangle-shaped whoop board! The Diamond F4 5-in-1 AIO board makes building whoops easy as picking your camera, motors, and frame.
*Direct replacement AIO for the Moblite6/Moblite 7 whoops
*ELRS VersionSKU: HM.DIAMF4.FC.ELRS. -
Electronics, Flight Controllers
Happymodel ELRS 2G4 Whoop Flight Controller
The world’s first AIO 5in1 F4 flight controller with integrated SPI 2.4GHz ExpressLRS receiver has been launched. The flight controller integrates SPI controlled 2.4GHz ExpressLRS receiver, Dshot protocol 4-in-1 ESC, 5.8GHz 40ch video transmitter and Betaflight OSD. Ultra-small size and ultra-stable remote control range can improve the range of the original SPI receiver. And because the 2.4GHz ExpressLRS receiver is equipped with the SX1280 radio frequency chip with high sensitivity, high packet rate and low latency, this flight controller is the one that all Race/Freestyle pilots needed. It is suitable for use in Tiny whoop Race or Toothpick Freestyle, and can also be used in 1S ultra-lightweight Nano Long Range platform.
SKU: HM.2G4.FC.ELRS. -
Category Name, Electronics, ELRS Receivers
Happymodel EP1 2.4GHz RX ELRS Receiver
The PP RX is designed by @Jye Smith from ExpressLRS development team. Its main hardware architecture is STM32L432KBU6 MCU and SX1280 RF chip. On the basis of PP RX, we have developed the Nano 2.4GHz rx of ESP8285 version named EP1 and EP2. The RF module of EP1/EP2 is the same like PP RX and use ESP8285 MCU . So you can upgrade firmware by WIFI , that’s too simple. Due to the low-latency and high-refresh-rate RF module, they are very comfortable for FPV race and Long Range FPV. And very suitable for whoop because of the ultra light and Nano size.
SKU: HM.EP1.RX.ELRS. -
Electronics, ELRS Receivers
HappyModel EP2 2.4GHz RX ELRS Receiver
Happymodel’s 2.4GHz ELRS nano series receiver with tiny ceramic antenna.
The PP RX was designed by @Jye Smith from the ExpressLRS development team. Its main hardware architecture is STM32L432KBU6 MCU and SX1280 RF chip. It has a built-in ceramic antenna, which is super light and small in size.
On the basis of that PP RX, Happymodel has developed the Nano 2.4GHz RX of ESP8285 version named EP1 and EP2. The RF module of EP1/EP2 is the same as PP RX and uses ESP8285 MCU. You can upgrade firmware via WiFi!
Due to the low-latency and high-refresh-rate RF module, they are very comfortable for FPV race and Long Range FPV. These are very suitable for Tiny Whoops because of the ultra-light and Nano size!Note: This is the EP2 RX Version
SKU: HM.EP2.RX.ELRS. -
Electronics, Other Electronics
Happymodel EP82 VRX-Backpack Module
So what is this VRX backpack? This Happymodel “backpack”is designed to allow wireless communication between ExpressLRS, and other FPV-related devices for command and control, or for querying config. Currently there aren’t many VRX modules that can allow them to communicate with ELRS. This small ESP-based receiver can be “piggybacked” onto your VRX module, which allows ExpressLRS to control the band and channel that your goggles are set to. We call this device the “VRX-Backpack”.
SKU: HM.EP82.VRX.ELRS. -
Electronics, Flight Controllers
Happymodel Pancake 2-6S F4 AIO Flight Controller SPI ELRS RX + 5.8GHz OpenVTX
Electronics, Flight ControllersHappymodel Pancake 2-6S F4 AIO Flight Controller SPI ELRS RX + 5.8GHz OpenVTX
The Pancake AIO was designed with the help of the ExpressLRS team. It features an onboard 2.4GHz ELRS SPI receiver as well as a 5.8 GHz OpenVTX with up to 400mw of power. It can be mounted using the 30.5mm or 20mm spaced holes.
SKU: HM.PANCAK.FC.ELRS. -
Electronics, Flight Controllers
Happymodel SuperbeeF4 Lite AIO 1S FC 2.4GHz ELRS
The direct replacement AIO board for the Mobula6 HDZero. The default OSD is set to “MSP” since this is considered spare part for the Mobula6 HDZero.
If using this board with an analog camera you will need to change some settings in BetaFlight. Instructions can be found at SuperbeeF4
* ELRS version
SKU: HM.SPBEF4.FC.ELRS. -
Category Name, Electronics, Other Electronics
Happymodel Tango 2 Power Adapter for ES24TX Slim Pro 1W Output
Category Name, Electronics, Other ElectronicsHappymodel Tango 2 Power Adapter for ES24TX Slim Pro 1W Output
This set of power adapters consists of two parts, one of which is a PCB board directly glued to the back of the main board of the Tango2. Another PCB with pins directly replaces the original external expansion module. This allows you to run your Tango 2 at 1W with the ES24TX Slim Pro module.
SKU: HM.ADAPT.TG2 -
Electronics, Flight Controllers
Happymodel X12 1-2S AIO Whoop F4 Flight Controller 12A ESC – ELRS version
Electronics, Flight ControllersHappymodel X12 1-2S AIO Whoop F4 Flight Controller 12A ESC – ELRS version
Happymodel X12 is a 5-in-1 AIO board featuring an F4 Flight Controller. It has an onboard 12A 4-in-1 ESC, 5.8GHz OpenVTX, with ELRS. This AIO has nice 400mw range great for any brushless whoop.
SKU: HM.X12.FC.ELRS. -
Electronics, Flight Controllers
Happymodel X2 AIO F4 Flight Controller SPI ELRS RX 2-4S 12A ESC
The Happymodel ELRS X2 AIO Flight Controller is the direct replacement for the Mobula7 HDZero.
It comes with an integrated SPI 2.4GHz ELRS receiver and 12A Blheli_S ESC which supports 2-4S batteries. Bigger mosfet supports high to 12A currents and would be better for a 2-4S toothpick drone or long-range FPV drone. The 2.4GHz ExpressLRS receiver is equipped with the SX1280 radio frequency chip with high sensitivity, high packet rate, and low latency. Featuring an MPU 6000 SPI sensor and OSD, this board is the perfect addition to your FPV build.
SKU: HM.X2F4.FC.ELRS. -
Category Name, Electronics, ELRS Receivers
RadioMaster RP1 2.4GHz ELRS v3 Nano Receiver
These RadioMaster nano receivers, developed by Jye Smith of ExpressLRS, have ESP8285 MCU and SX1280 RF chip. RP1 has a UFL antenna socket while RP2 has a built-in ceramic antenna, making it super light and small. Both have WIFI built in, allowing you to upgrade firmware and configure the Receiver via WebUI. Both RP1 and RP2 have low-latency, high-refresh-rate RF module, making them ideal for FPV and long-range. Furthermore, their ultra-light Nano size allows you to fit them anywhere, from whoops to fixed-wing models. The RP1 comes with ELRS Firmware V3 pre-installed.
Note: The packaging in this product will refer to ELRS V2 pre-installed, it has been confirmed ELRS V3 is pre-installed.
SKU: RM.RP1.RX.ELRS -
Category Name, Electronics, ELRS Receivers
RadioMaster RP2 2.4GHz ELRS Nano Receiver v2
The RadioMaster RP2 ExpressLRS 2.4ghz Nano Receiver w/ Fixed SMT Antenna is an open-source receiver based on ExpressLRS. It features an ESP8285 MCU and an SX1280 RF chip. The RP2 has a built-in ceramic antenna which is super light and small in size and ideal for racing. The RP2 features WIFI built in so you can upgrade firmware by WIFI and configure the Receiver via the built-in WebUI with your PC or mobile phone. Due to the low-latency and high-refresh-rate RF module, the RP2 is ideal for FPV racing or Long Range flights. Suitable for whoops, drones, and fixed-wing models due to the ultra-light and Nano size, these receivers can fit just about anywhere!
Features
- Built-in WIFI so you can upgrade firmware by WIFI and configure the Receiver via the built-in WebUI with your PC or mobile phone
- Upgraded rigid antenna with greater durability and performance
- Improved PCB design is better for heat dissipation
- Solder pads are improved and easier to solder to
- Low-latency and high-refresh-rate RF module
- Open-source receiver based on ExpressLRS
- LED on the top side of PCB
- Built-In ceramic antenna
- SX1280 RF chip
- ESP8285 MCU
SKU: RM.RP2.RX.ELRS.V2.
