Other Electronics
Showing all 17 results
-
Category Name, Electronics, Other Electronics
DarwinFPV Tiny Ape VTX 25/200/400/600 mW
DarwinFPV 600mW VTX is a light weight, small size, high quality 25-600mW VTX, it provides optional 25/200/400/600mW output power, integrated 4Pin socket, plug and play is very convenient. The VTX settings can be adjusted through the flight control, that is, the transmitted power, frequency band and channel.
Indicator Light Description:
Frequency and Power Control Method:
Adjust VTX frequency and power via Betaflight
①Connect the RX white line of VTX to the TX signal line or SOFTSERIAL1 signal line of the FC spare UART port;
②Select the port tab, enable the TBS (SmartAudio) function setting of the connected port and save it;(The above figure takes the TX signal line as an example; SOFTSERIAL1 is the same, just select the TBS (SmartAudio) function according to the corresponding port).
③ After entering the VTX parameter adjustment interface, select the desired frequency and power, and then “save” to save and exit.
SKU: DF.VTX.TINYAP. -
-
Analog, Category Name, Electronics, FPV Equipment, Other Electronics
Flywoo Finder Buzzer w/LED v1.0
The Finder is compatible with all BF and CF flight controls. Just connect to the buzzer interface of the flight controller and it will work. When the flight control wiring is correct, the multi-rotor aircraft is powered on, and the flight control power supply will be automatically charged for the Finder (the red LED will light to indicate charging is in progress, the red light is off to indicate charging saturation; the red light flashing indicates flight control) Electricity, enter 30 seconds waiting time).
The buzzer has two modes of operation
- It is compatible with the functions of the traditional active buzzer and synchronized with the flight control.
- When the flight control is normally connected, if the main battery in the flight is powered off, it can still automatically emit 100 dB of drip sound after 30 seconds of power failure, and the LED will emit white light.
To turn off the buzzer
Press and hold the release button for more than 2 seconds, the Finder V1.0 turns off the sound.
SKU: FW.FINDER.BUZZER. -
Category Name, Electronics, Other Electronics
Flywoo GOKU GM10 Mini V3 GPS
Flywoo’s GOKU GM10 V3 GPS series has arrived! Using the latest M10050 GNSS chip. Compared with the previous generation GM8 V2, the positioning is more accurate, and the speed of satellite search is faster.
Note: The chip of GOKU GM10 V3 GPS is M1005. Only BF4.3x version firmware can use Ublox protocol. BF4.2x and earlier firmware can only use NMEA protocol But there is no difference in performance between the two protocols
BETAFLIGHT:
Use firmware above 4.3.0
INAV:
Use the latest 6.0.0 configurator, the latest firmware above 5.0.0SKU: FW.10MV3.GPSM. -
Category Name, Electronics, Other Electronics
Flywoo GOKU GM10 Nano V3 GPS
The GOKU GM10 V3 GPS series has arrived! Using the M100500 GNSS chip. Compared with the previous generation GM8 V2, the positioning is more accurate, and the speed of satellite search is faster.
Note: The chip of GOKU GM10 V3 GPS is M1005. Only BF4.3x version firmware can use Ublox protocol. BF4.2x and earlier firmware can only use NMEA protocol But there is no difference in performance between the two protocols
BETAFLIGHT:
Use firmware above 4.3.0
INAV:
Use the latest 6.0.0 configurator, the latest firmware above 5.0.0SKU: FW.10NV3.GPSM. -
Electronics, Other Electronics
Happymodel EP82 VRX-Backpack Module
So what is this VRX backpack? This Happymodel “backpack”is designed to allow wireless communication between ExpressLRS, and other FPV-related devices for command and control, or for querying config. Currently there aren’t many VRX modules that can allow them to communicate with ELRS. This small ESP-based receiver can be “piggybacked” onto your VRX module, which allows ExpressLRS to control the band and channel that your goggles are set to. We call this device the “VRX-Backpack”.
SKU: HM.EP82.VRX.ELRS. -
Category Name, Electronics, Other Electronics
Happymodel Tango 2 Power Adapter for ES24TX Slim Pro 1W Output
Category Name, Electronics, Other ElectronicsHappymodel Tango 2 Power Adapter for ES24TX Slim Pro 1W Output
This set of power adapters consists of two parts, one of which is a PCB board directly glued to the back of the main board of the Tango2. Another PCB with pins directly replaces the original external expansion module. This allows you to run your Tango 2 at 1W with the ES24TX Slim Pro module.
SKU: HM.ADAPT.TG2 -
Category Name, Electronics, Other Electronics
RunCam Thumb 1080P Mini Action Camera with 3D Mount
The RunCam Thumb is a mini-sized action camera with a 1080P 60FPS resolution. This camera is perfect for RC fanatics looking to capture action shots without much-added weight, coming in at just 9.8g! The Thumb has a built-in Gyro sensor to help get that perfect cinematic footage. A 3D printed case, a standard mounting case, and an ND Filter included.
Manual Download
Instructions to record gyro data along with video for later use in gyroflow:
Create a csvopen.txt file manually to the root directory of the camera’s microSD card.
It will take effect only after the camera is restarted. At this time, the camera will keep
1080p50fps video and gyroscope data at the same time in the SD card.SKU: RC.CAM.THUMB. -
Category Name, Electronics, Other Electronics
RunCam Thumb Pro 4K HD Action Camera
The RunCam Thumb Pro is the next big thing in mini-action cameras. Coming in at an ultralightweight of 16g, this camera is perfect for your next FPV micro flight! This mini camera features 4K resolution and allows you to shoot in a horizontal or vertical orientation through remote control HD recording. The built-in gyro supports Gyroflow to perfectly output smooth and stabilized video. A replaceable lens protector cover allows for the addition of ND filters for better light control.
Suitable for 2″ and 2.5″ CineWhoops!
Link to manual
** IMPORTANT NOTE:
Please note you must use an external power supply (Flight Controller). Doesn’t use external battery. See manual link above for connection instructions.SKU: RC.CAM.THUMB.PRO. -
Batteries/Chargers, Battery Chargers/Testers, Category Name, Electronics, Other Electronics
TuneRC 1S LiPo Battery Storage Discharger for PH2.0
Batteries/Chargers, Battery Chargers/Testers, Category Name, Electronics, Other ElectronicsTuneRC 1S LiPo Battery Storage Discharger for PH2.0
Tired of puffy batteries? Storage charge your battery safely! Ready to fly but bad weather or something else ruins your plans? Leaving all your 1S batteries fully charged, which will cause puffing and lower your batteries’ life span. This 1S discharger is a great way to avoid this. It stops discharging completely when done, so you can be sure your 1S batteries are safe. Easy to use – just plug the 1S battery in and the red LED will light up. Once the discharging is complete, the LED will turn off. If the LED doesn’t turn on, press the button to switch the discharger to working mode.
SKU: TR.CH.D005. -
Category Name, Electronics, Other Electronics
TuneRC Buzzer V2 with Built-in Driver Circuit
TuneRC Buzzer has a driver circuit built in, so you can connect it to any flight controllers as long as there’s a free/available port on it. It is an alarm system that will help you locate your drone.
Feature:
- V2 update of this buzzer comes with a Plug-in style configuration for ease of use.
How to Connect the Buzzer to Flight Controllers that features “Buzzer+” “Buzzer-” Soldering Pads?
You just need to wire the buzzer with the flight controller as per the instruction below. Note: You don’t need to do the mapping in Betaflight.
FC “Buzzer+” — Buzzer Red Wire (3V-5V)
FC “GND”— Buzzer Black Wire (GND)
FC “Buzzer-” — Buzzer Blue Wire (Signal)How to Connect the Buzzer to EZ F411 AIO and Other Flight Controllers that don’t Feature Buzzer Pads?
Step 1. Firstly, please solder the buzzer’s signal wire ( blue wire) to any available/free port on the flight controller.
For example, RX1 is mostly the available port on the EZ AIO, so you can connect the
FC RX1 with the Buzzer Signal Wire (Blue Wire), FC 5V–Buzzer 3V-5V (Red Wire), FC GND–Buzzer GND (Black Wire)Step 2. In Betaflight, Enter “resource” in the CLI to find out the pin number corresponding to the port.
For example, pin number on the EZ corresponding to RX1 is A10.Step 3. Free the available port in the CLI and then set the corresponding pin as beeper, finally enter “save” in the CLI
For example, on the EZ AIO board, in the CLI, enter “resource serial_RX 1 NONE” , and then enter “resource beeper 1 A10”. Finally enter “save” and you are done.SKU: TR.BZ.D002. -
Electronics, Other Electronics
ViFly Beacon Wireless Self-Powered Drone Buzzer
VIFLY Beacon is an advanced self-powered drone buzzer for any types of quads. Based on the motion sensor, it can detect the abnormal movement of the quads and make the alarm automatically to help you find the lost quad easily when the quad crashed. Some aerial drones like DJI have GPS, but it only provides you the draft location when you crash it, with the sound help, you can find your quad precisely. Very easy to setup, everyone can make it work even you are a newbie. Install it on your DJI quads, FPV quads or airplanes to prevent the drone losing again.
Main Features:
Lost Drone Alarm by Motion Sensor
Some drones like DJI models are installed with GPS that only provide you the draft location, with the sound help, you can find your lost drone precisely. With the built-in motion sensor and lipo battery, VIFLY Beacon can detect the drone crash automatically and make the alarm to help you locate the lost drone.
Wireless, No Soldering Required
The mechanism of VIFLY Beacon is based on the motion sensor, attach it anywhere on the drone to detect the movement, no wire, no soldering.
Loud Sound & Bright LED
To easily find the lost drone in long distance, VIFLY Beacon is installed with a very loud beeper that the dB is over 100. In addition, the LED on VIFLY Beacon can flash automatically when the built-in light sensor detects the light darkness.
Anti Theft Technology
If someone wants to take the done away when it is in alarm status, VIFLY Beacon will beep continuously to warn the picker.
Position Light at Night
VIFLY Beacon LED light can flash automatically at night to make the drone visible when the built-in light sensor detects the darkness.
SKU: VF.BEACON. -
Electronics, Other Electronics
ViFly Cam Switcher
Because sometimes two cameras are better than one! Via your Radio transmitter you can switch between two FPV cameras.
Fast Camera Switching (Connecting Receiver Directly)
No matter it is PWM radio receiver on the airplane or the SBUS/IBUS/DSMX radio receiver on racing quad, VIFLY Cam Switcher has the ability to take the signal from both of them via our advanced program. Not like other products to take the racing quad signal through the flight controller, VIFLY Cam Switcher connects the receiver directly that minimizes transition time and gets faster response. It is the time to build your CheaterKwad for more fun.Easy Setup and no Betaflight Configuration
Though SBUS/IBUS/DSMX radio receivers on racing quad lack PWM channel outputs, VIFLY Cam Switcher can take the signal from the receiver directly through its own algorithm. It doesn’t depend on the flight controller and no need to set the PINIO feature in Betaflight that the setting is very complicated for most of FPV fliers.Compatible with Racing Quads and Airplanes
VIFLY Cam Switcher is a smart accessory to take the signal from PWM receiver and SBUS/IBUS/DSMX receiver. Now you can easily switch the two cameras on racing drone or RC plane.
Tiny and Lightweight
The size is super small, at only 9x18mm, it’s also a great choice for micro quads and airplanes. The weight is 0.5g that almost has no impact on high performance models.SKU: VF.CAMSWI. -
Category Name, Electronics, Other Electronics
ViFly Finder Mini Drone Buzzer with Battery
The ViFly Finder Mini is a smaller version of ViFly Finder 2, weighs only 2.7g that would be the perfect drone buzzer for compact builds and small drones. After searching and testing a large number of beepers, VIFLY Finder Mini uses the loudest buzzer that can be found in this tiny size, the volume can be up to 100 dB. Almost half size and weight of VIFLY Finder 2, but the volume is not lower too much.
SKU: VF.MFINDR. -
Electronics, Other Electronics
ViFly GPS-mate External GPS Power Module
Tired of draining your battery as you wait for the GPS fix? Wish the GPS was self-powered so that it didn’t have to get a new fix every time you plug up a new pack? Battery ejected during crash and now the GPS is useless? The GPS-mate is what you’re looking for!
Why Vifly designed the GPS-mate?
Most drone pilots have a problem when using the GPS on their drones. GPS modules are slow, and get interference. To get a fix, a pilot must wait many minutes for a GPS fix. To do this, everything must be powered, which drains the battery and causes extra interference. It also has potential risk to cause overheating issues to your quad components. In addition, when you finish a flight cycle and change the quad battery, the GPS needs to get a hot-start fix as the quad battery disconnected. We want to fix the pain, so we design and produce GPS-mate, the external power module just for GPS.What exactly does the GPS-mate do?
VIFLY GPS-mate is an external power module just for GPS, there is a switch to turn on and off the unit. With this device, once the pilot wants to fly, he flips the switch and only the GPS gets powered. When the GPS fix finished, the pilot connects the drone LiPo. The drone LiPo powers the drone, and recharges the GPS battery. The GPS never loses power until the switch is turned off, so the pilot never needs to get another fix for the whole session.We also embed VIFLY Finder 2 function into this device, it can work as a standard buzzer that controlled via your radio when the quad battery is connected, it also can work as a standalone buzzer that help you find the lost drone when the main battery has been ejected.
SKU: VF.GMATE.MODULE. -
Category Name, Electronics, FPV Accessories, FPV Gear, Other Electronics
ViFly Short Saver 2 Smoke Stopper XT30 & XT60
Category Name, Electronics, FPV Accessories, FPV Gear, Other ElectronicsViFly Short Saver 2 Smoke Stopper XT30 & XT60
The newest V2 of the ShortSaver from ViFly!
Completely cut off the current flow and prevent “magic smoke”
- For other smoke stoppers like the automotive light-bulb or resettable fuse, they just limit not stop the current flow, the leakage current may still damage your components. VIFLY ShortSaver is a different smoke stopper that adopts the electronic fuse to completely cut off the current into your RC build if a short circuit or wiring mistake is detected.
Super-fast reaction/protection time
- VIFLY ShortSaver would turn off the power to a device that drew in excess of the switchable 1A or 2A threshold within just 3ms. It is far more effective than the old way of using light-bulb or resetting fuse. The shorter the protection time, the safer your build will be as something make break by the time the fuse trips.
1 Amp and 2 Amp Threshold Selector
- VIFLY ShortSaver is so smart that there is 1 Amp or 2 Amp threshold selector for your different needs. For small size build with more sensitive electronic components, you can select 1 Amp option, for large builds, 2 Amp option is the choice.
Amass XT60 and XT30 In-output Connectors
- VIFLY ShortSaver is coming with both Amass XT30 and XT60 connectors, more convenient for your different batteries.
SKU: VF.SSAVR2.
